HPE MSA 2062 16Gb Fibre Channel SFF Storage – R0Q80B, with 2 × 1.92TB SSD, dual 4-port 16Gb FC controllers and Advanced Data Services license.

HPE MSA 2062 16Gb Fibre Channel SFF Storage | R0Q80B

The HPE MSA 2062 16Gb Fibre Channel SFF Storage (R0Q80B) is a flash-enabled Gen6 SAN storage array featuring an HPE MSA 2060 SFF chassis, two 4-port 16Gb Fibre Channel controllers, two 1.92TB Read Intensive SFF SSDs, and a pre-installed Advanced Data Services license. It supports up to 24 SFF drives in the base enclosure and can be expanded with additional MSA 2060 SFF or LFF drive enclosures.

Controller Configuration

2 × HPE MSA 2060 16Gb Fibre Channel Storage Controllers

• 4 × 16Gb Fibre Channel ports
• Redundant controller architecture
• Independent host connectivity

8 × 16Gb Fibre Channel host ports

Included SSD Storage

2 × 1.92TB Read Intensive SFF SSD

Total raw flash capacity: 3.84TB

These two SSDs are factory integrated into the array. HPE describes the MSA 2062 as starting with 3.84TB of embedded flash capacity.

Drive Capacity

24 × 2.5-inch SFF drives

• Read Intensive SSD
• Enterprise SAS HDD
• Midline SAS HDD

HPE currently lists SFF SSD capacities of 960GB, 1.92TB, 3.84TB and 7.68TB, while SFF 10K HDD options include 600GB, 1.2TB, 1.8TB and 2.4TB.

Expansion

The MSA 2062 can be expanded with up to 9 additional MSA 2060 drive enclosures.

Supported expansion includes:

SFF

24-drive SFF enclosure

LFF

12-drive LFF enclosure

HPE also supports mixing SFF and LFF array/enclosures.

Maximum configuration

Fibre Channel Connectivity

The R0Q80B is the 16Gb Fibre Channel version of the MSA 2062.

Connectivity

• 8 × 16Gb FC host ports
• 4 ports per controller
• 2 redundant controllers
• 8/16Gb Fibre Channel connectivity
• Auto-negotiation down to 8Gb FC

SFP+ requirement

FC SFP+ transceivers are not included.

HPE specifies that MSA 2062 FC systems require the appropriate Gen6 SFP option. The recommended 4-pack for this model is:

C8R24B — HPE MSA 16Gb Short Wave Fibre Channel SFP+ 4-pack Transceiver

A minimum of one 4-pack is required for Fibre Channel models.

This is particularly relevant to your inventory because you have C8R24B in stock.

Storage Features

• Thin Provisioning
• Space Reclamation
• Thin Rebuild
• Automated Tiering
• SSD Read Cache Extension
• Volume Copy
• Snapshots
• Remote Snap
• Virtual Tier Affinity
• MSA-DP+

RAID Support

• RAID 0 — Read Cache Only
• RAID 1
• RAID 5
• RAID 6
• RAID 10
• MSA-DP+

MSA-DP+

MSA-DP+ provides:

• Integrated sparing
• Fast rebuilds
• Improved sequential performance
• Incremental disk-group expansion

Advanced Data Services

The Advanced Data Services LTU is included and pre-installed with MSA 2062.

• Advanced snapshots
• Remote Snap
• Volume Copy
• Thin Provisioning
• Storage management features

HPE specifies 64 snapshots per array as standard, increasing to 512 snapshots with the Advanced Data Services license.

Cache & System Resources

Power

• 2 × AC power supplies
• Redundant power configuration
• 2 × 1.5m PDU power cords
• 94% efficient power supplies on the B-suffix SKU

Physical Dimensions

HPE's datasheet gives the dimensions as 8.9 × 44.5 × 50.8 cm and weight as 5.0kg.

Operating System / Platform Support

• Windows Server 2022
• Windows Server 2019
• Windows Server 2016
• VMware vSphere 6.7
• Red Hat Linux 8
• SUSE SLES 15

What Is Included

• HPE MSA 2060 SFF array chassis
• 2 × MSA 2060 16Gb FC controllers
• 2 × 1.92TB Read Intensive SFF SSD
• Advanced Data Services LTU
• 2 × AC power supplies
• 2 × 1.5m PDU cords
• Rack-mount kit

Not included:

• FC SFP+ transceivers
• Additional HDDs/SSDs
