The HPE MSA 2062 10GbE iSCSI SFF Storage (R0Q82B) is a 2U hybrid-flash SAN storage array designed for SMB, remote-office, virtualization, and application workloads. It includes dual 10/25GbE iSCSI controllers, two 1.92TB Read Intensive SFF SSDs, 24 SFF drive bays, and an Advanced Data Services license.

Storage Controllers

2 × HPE MSA 2060 10/25GbE iSCSI Storage Controllers

• 4 × 10/25GbE iSCSI ports
• Redundant controller architecture
• Multiple host connectivity paths

4 ports × 2 controllers = 8 total iSCSI host ports.

10GbE / 25GbE iSCSI Connectivity

Included SSD Storage

2 × 1.92TB Read Intensive SFF SSD

1.92TB × 2 = 3.84TB

These are 2.5-inch SFF Read Intensive SSDs.

Drive Bays

24 × SFF 2.5-inch drives

• SSD
• Enterprise SAS HDD
• Midline SAS HDD
• Self-encrypting drives, where supported

The MSA 2062 can combine SSD and HDD media to create a hybrid-flash storage system.

Expansion

SFF expansion

24-drive SFF MSA 2060 expansion enclosure

LFF expansion

12-drive LFF MSA 2060 expansion enclosure

Maximum Storage Capacity

Advanced Data Services License

• Snapshots
• Volume Copy
• Remote Snap
• Thin Provisioning
• Storage tiering

Hybrid Flash Architecture

SSD + Enterprise SAS HDD + Midline SAS HDD

• Performance
• Capacity
• Cost

Performance

• Drive configuration
• RAID/data protection configuration
• Workload
• Host connectivity
• Cache
• Number of controllers/paths
• Application workload

Data Protection

• RAID 0
• RAID 1
• RAID 5
• RAID 6
• RAID 10
• MSA-DP+

MSA-DP+

HPE's MSA-DP+ technology provides distributed spare capacity across the disk group rather than relying on a traditional dedicated hot spare.

• Rebuild performance
• Storage utilization
• Availability

Automated Tiering

MSA 2062 supports automated storage tiering.

SSD → Performance

Enterprise SAS HDD → Standard

Midline SAS HDD → Capacity

Remote Replication

The MSA 2062 supports Remote Snap for replication.

• Disaster recovery
• Data replication
• Secondary storage systems
• Business continuity

HPE specifically identifies remote replication over Fibre Channel or iSCSI as a supported MSA 2062 capability.

Virtualization

The MSA 2062 is designed for virtualized environments and supports VMware environments.

• VMware vSphere 6.7
• Windows Server 2016
• Windows Server 2019
• Windows Server 2022
• Red Hat Linux 8
• SUSE SLES 15

Form Factor & Physical Dimensions

Rack Size

2U

Dimensions

8.9 × 44.5 × 50.8 cm

Weight

5.0 kg

Power

• 2 × AC power supplies
• Redundant power architecture
• 1.5m PDU power cords

SFP Transceivers

SFP transceivers are NOT included with R0Q82B.

HPE states that SFPs are not included with the base MSA 2062 storage systems. Appropriate Gen6 SFP options must be purchased separately for the Fibre Channel and 10GbE iSCSI models.

For 10Gb iSCSI, HPE offers the appropriate short-range SFP+ transceiver options.

Complete Technical Specification

* HPE's stated performance figure is based on its internal testing methodology.

What is Included?

• HPE MSA 2062 SFF storage array
• MSA 2060-branded SFF chassis
• 2 × 10/25GbE iSCSI controllers
• 2 × 1.92TB Read Intensive SFF SSDs
• 3.84TB total raw SSD capacity
• Advanced Data Services license
• 2 × AC power supplies
• 2 × 1.5m PDU power cords
• Rack-mount kit

Not Included

• ❌ 10GbE iSCSI SFP+ transceivers
• ❌ Additional storage drives

Difference MSA 2060 & MSA 2062

MSA 2060

• Can be a diskless/base array
• Drives are purchased separately
• Controller type depends on the specific SKU

MSA 2062

• Uses the same MSA Gen6 platform/chassis
• Comes with 2 × 1.92TB SSDs
• Includes Advanced Data Services
• Sold as a more complete hybrid-flash configuration
